Lightweight Flexible LED Film Screen P16 P32 P20 LED Display With Wide Viewing Angle
-
Highlight
Lightweight Flexible LED Film Screen
,Flexible LED Film Screen P16
,P20 LED Display Screen
-
NameFlexible LED Film Screen
-
LED SpecificationSMD2121 (light Drive In One)
-
Module Size1000mm*240mm
-
Pixel Pitch16mm*16mm（x*y）
-
Pixel3844points/m2
-
Viewing Angle≥160°
-
Weight≤ 3.5KG/m2
-
Place of OriginChina
-
Brand NameYUYI
-
CertificationCE ROHS FCC
-
Model NumberP16
-
Minimum Order Quantity1 square meter
-
PriceNegotiable
-
Packaging DetailsCarton/wooden case/flight case/customized
-
Delivery Time15-30 working days
-
Payment Terms,L/C,D/A,D/P,T/T,Western Union,MoneyGram
-
Supply Ability3000 pieces/day
Lightweight Flexible LED Film Screen P16 P32 P20 LED Display With Wide Viewing Angle
High-Performance Flexible LED Film Screen P6 P8 P10 for Versatile Applications
As a technological product, YUYI LED film screen has irreplaceable advantages:
Ultra-light Weight and Ultra-thin
*Ultra-light weight and ultra-thin thickness make YUY LED film screen save more cost in transportation and save a lot of labor in installation,while the effect after installation is also better!
Low Brightness and High Gray High Refresh Rate
*3840HZ refresh rate,fast corresponding .No screen drag, no flickering situation.The screen display process is clear.
Wide Viewing Angle
*160° for each angle, no dead Angle and no color bias.Making the visual experience even better.
Stable Operation
*Using a specific bare chip, components are solidly mounted on a highly transparent flexible film, and through a unique capping process,the display module is integrated into a high-transparencyoptical lens-type substrate that can emit light for display.
| Product specification | P4-4 | P4-8 | P6 | P8 | P10 | P16 | P16-32 | P20-60 | P32 |
| Pixel pitch | 4mm*4mm(x*y) | 4mm*8mm(x*y) | 6mm*6mm(x*y) | 8mm*8mm(x*y) | 10mm*10mm(x*y) | 16mm*16mm(x*y) | 16mm*32mm(x*y) | 20mm*60mm(x*y) | 32mm*32mm(x*y) |
| Pixel | 62500p;points/m2 | 31250 points/m2 | 27556 points/m2 | 15625 points/m2 | 10000 points/m2 | 3844points/m2 | 1922points/m2 | 800points/m2 | 961points/m2 |
| LED specification | SMD1010 (light drive in one) | SMD1010 (light drive in one) | SMD2121 (light drive in one) | SMD2121 (light drive in one) | SMD2121 (light drive in one) | SMD2121 (light drive in one) | SMD2121 (light drive in one) | SMD2121 (light drive in one) | SMD2121 (light drive in one) |
| Pixel composition | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
| Module Size | 800mm*240mm | 1000mm*240mm | 1000mm*240mm | 1000mm*240mm | 1000mm*240mm | 1000mm*240mm | 1000mm*240mm | 1000mm*240mm | 1000mm*240mm |
| Module Resolution | 200*60 | 250*30 | 166*40 | 125*30 | 100*24 | 62*15 | 62*7 | 50*4 | 31*7 |
| Pixel resolution | 250*250/㎡ | 250*125/㎡ | 166*166/㎡ | 125*125/㎡ | 100*100/㎡ | 62*62/㎡ | 62*31/㎡ | 50*16/㎡ | 31*31/㎡ |
| Permeability | ≥85% | ≥85% | ≥85% | ≥85% | ≥90% | ≥90% | ≥95% | ≥95% | ≥95% |
| Box wiring mode | Internal wiring (clean back) | Internal wiring (clean back) | Internal wiring (clean back) | Internal wiring (clean back) | Internal wiring (clean back) | Internal wiring (clean back) | Internal wiring (clean back) | Internal wiring (clean back) | Internal wiring (clean back) |
| Weight | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 |
| White balance brightness | ≥3000cd/㎡ | ≥3000cd/㎡ | ≥3000cd/㎡ | ≥3500cd/㎡ | ≥3500cd/㎡ | ≥3500cd/㎡ | ≥2500cd/㎡ | ≥600~800cd/㎡ | ≥1500cd/㎡ |
| Peak power consumption | 400 W/㎡ | 400 W/㎡ | 400 W/㎡ | 400 W/㎡ | 400 W/㎡ | 400 W/㎡ | 400 W/㎡ | 400 W/㎡ | 400 W/㎡ |
