320*160mm 256*128mm Full Color LED Display Module For LED Video Wall Panel
-
Highlight
320*160mm Full Color LED Display Module
,256*128mm Full Color LED Display Module
,Full Color LED Display Wall Panel
-
Brand NameYuyi
-
ApplicationOutdoor
-
UseAdvertising Publish, Retail Store, Shopping Mall, Display Of Dishes, Welcome Display, Self-service Business, Exhibition Hall, Wayfinding, Airport, Subway, Elevator, Restaurant & Hotel Supplies, Education, Medical Treatment
-
Media AvailableDatasheet
-
ColorFull Color
-
Model NumberP8
-
Place Of OriginShenzhen China
-
Product NameOutdoor Led Display Panel P8
-
Brightness6500cd/sqm
-
LED Chip3535
-
Warranty2 Years
-
Module Size320*160mm/256*128mm
-
Resolution120*120
-
Pixel Density15625dots/sqm
-
Scan Mode1/4scan
-
Life Span100000hours
-
Weight41kg
-
Pixel Pitch8mm, 8mm
-
Supplier TypeOriginal Manufacturer, ODM, OEM
-
FunctionSDK
-
SpecificationVideo Wall
-
Panel Size960*960mm/Customization
-
PortShekou Shenzhen
-
NameOutdoor Fixed LED Display
-
PriceCN¥3,160.17/pieces 1-19 pieces
-
Packaging Details1.wooden case<br>2.flight case
-
Supply Ability2000 Square Meter/Square Meters per Month
320*160mm 256*128mm Full Color LED Display Module For LED Video Wall Panel
Product Description
Specification
|
Product Name
|
p4
|
p5
|
p6
|
p8
|
p10
|
||||
|
Pixel Pitch
|
4mm
|
5mm
|
6mm
|
8mm
|
10mm
|
||||
|
Pixel Density
|
62500dots/m2
|
40000dots/m2
|
27777dot/m2
|
15625dots/m2
|
10000dots/m2
|
||||
|
Module Size
|
256*128mm
|
320*160mm
|
192*192mm
|
320*160mm
|
320*160mm
|
||||
|
Cabinet Size
|
1024*1024mm
|
960*960mm
|
960*960mm
|
960*960mm
|
960*960mm
|
||||
|
Cabine Weight
(±0.05kg)
|
44kg
|
43kg
|
42kg
|
41kg
|
40kg
|
||||
|
Cabinet Resolution
|
192*192
|
192*192
|
160*160
|
120*120
|
96*96
|
||||
|
Scan mode
|
1/8scan
|
1/8scan
|
1/8scan
|
1/5scan
|
1/4scan
|
||||
|
LED Chip
|
1921/2525
|
2525/2727
|
2525/2727
|
3535
|
3535
|
||||
|
Best Viewing Distance
|
4-45m
|
5-72m
|
6-80m
|
8-90m
|
10-100m
|
||||
|
Bightness
|
7000cd/spm
|
6500cd/spm
|
6500cd/spm
|
6500cd/spm
|
6500cd/spm
|
||||
|
Life Span
|
≥100,000 hours
|
|
|
|
|
||||
|
Power Supply
|
AC 110V/220V +-10%
|
|
|
|
|
||||
|
Waterproof Grade
|
Front: IP65 Rear: IP54
|
|
|
|
|
||||
|
Control System
|
LINSN or Novastar or as you required
|
|
|
|
|
||||
Company Profile
Shenzhen Yuyi Photoelectric Co., Ltd. is a production, sales, service as one of the industry and trade companies, the company to implement high quality, positive, united as one enterprise team culture.
We mainly provide a full range of indoor and outdoor full-color LED modules, full-color LED display, full-color LED display series products.Our products are widely used in airports, banks, stadiums, concerts, shopping malls, surveillance centers and advertising and entertainment fields.Our products are exported to Europe, North America, Asia, and even exported to the Middle East and Africa, and are well received by consumers.
We mainly provide a full range of indoor and outdoor full-color LED modules, full-color LED display, full-color LED display series products.Our products are widely used in airports, banks, stadiums, concerts, shopping malls, surveillance centers and advertising and entertainment fields.Our products are exported to Europe, North America, Asia, and even exported to the Middle East and Africa, and are well received by consumers.
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
Q1:Are you a factory or trading company?
A;YUYI optoelectronic co.,ltd is an OEM/ODM factory,It is also a company integrating industry and trade.
Q2.what can you buy from us?
A:LED Display,LED Mudule,LED Screen,LED Wall,LED Display Rental
Q3: Where is your nearst port?
A : Our nearst port is shenzhen Shekou.
Q4: Are all of your products of good quality?
A: Yes, our products are of good quality, you don't have to worry about that. And we provide 2 years' warranty.
Q5: Can I visit your factory ?
A: We do have our factory, and you're welcomed to visit it at any time. The sales and the manager will accompany you to introduce our production line at that time.
Q6: What kind of packaging do you provide?
A: We provide flight case, wooden case and carton.
Q7: How can I select your product?
A: Firstly you need to tell us your requirement such as the viewing distance, size, installation height, and some other details for the LED screen that you want. And then we will give you a recommendation.
Q8: How long will it take me to get the product?
A: We will send the goods as quick as possible, but oftenly it will take 1-2 weeks to get the goods according to the distance ,and some other necessary processes.
A;YUYI optoelectronic co.,ltd is an OEM/ODM factory,It is also a company integrating industry and trade.
Q2.what can you buy from us?
A:LED Display,LED Mudule,LED Screen,LED Wall,LED Display Rental
Q3: Where is your nearst port?
A : Our nearst port is shenzhen Shekou.
Q4: Are all of your products of good quality?
A: Yes, our products are of good quality, you don't have to worry about that. And we provide 2 years' warranty.
Q5: Can I visit your factory ?
A: We do have our factory, and you're welcomed to visit it at any time. The sales and the manager will accompany you to introduce our production line at that time.
Q6: What kind of packaging do you provide?
A: We provide flight case, wooden case and carton.
Q7: How can I select your product?
A: Firstly you need to tell us your requirement such as the viewing distance, size, installation height, and some other details for the LED screen that you want. And then we will give you a recommendation.
Q8: How long will it take me to get the product?
A: We will send the goods as quick as possible, but oftenly it will take 1-2 weeks to get the goods according to the distance ,and some other necessary processes.
